SS 304 316 Woven Steel Wire Mesh Twill Reverse Dutch Filter For Pharmaceutical Industry

Place of Origin : Hengshui,China

MOQ : 1 roll

Price : 7-200 us dollar per square meter

Supply Ability : 3000 rolls per month

Packaging Details : Inside waterproof paper,outside wooden carton

Material : Stainless steel wire

Mesh size : 2 mesh-500meshes

Wire diameter : 0.018mm-2.05mm

Method : Hot Dipped or Electro Galvanized Bef.or Afterweave

Width : 0.5-6.5m

Length : 30m or customized

Feature : Wear-Resisting,Heat-Resisting,Acid-Resisting

Packing : Wooden carton

Contact Now

Ss 304 316 100 Mesh Stainless Steel Wire Mesh,Twill Reverse Dutch Woven Filter Stainless Steel Wire Mesh

Dutch wire mesh
Stainless steel dutch wire mesh is made of high quality stainless steel wire .The performance tested of Stainless steel is wear-resisting , heat-resisting , acid - resisting and corrosion resisting. Just because of these characteristics, the wire mesh made of stainless steel is extensively used in mining, chemical industry, food industry and pharmaceutical industry.

Maishi Plain Weave Stainless Steel Wire Mesh
Mesh/inch	Wire diameter (mm)	Aperture (mm)	--	Mesh/inch	Wire diameter (mm)	Aperture (mm)
2mesh	1.80	10.90		60mesh	0.15	0.273
3mesh	1.60	6.866		70mesh	0.14	0.223
4mesh	1.20	5.15		80mesh	0.12	0.198
5mesh	0.91	4.17		90mesh	0.11	0.172
6mesh	0.80	3.433		100mesh	0.10	0.154
8mesh	0.60	2.575		120mesh	0.08	0.132
10mesh	0.55	1.990		140mesh	0.07	0.111
12mesh	0.50	1.616		150mesh	0.065	0.104
14mesh	0.45	1.362		160mesh	0.065	0.094
16mesh	0.40	1.188		180mesh	0.053	0.088
18mesh	0.35	1.060		200mesh	0.053	0.074
20mesh	0.30	0.970		250mesh	0.04	0.061
26mesh	0.28	0.696		300mesh	0.035	0.049
30mesh	0.25	0.596		325mesh	0.03	0.048
40mesh	0.21	0.425		350mesh	0.03	0.042
50mesh	0.19	0.318		500mesh	0.025	0.0385
Technical Note: 1.Standard roll length:15.24m, 30m, 30.5m, 61m 2.Standard roll width:0.61m(2'), 0.9144m(3'), 1.22m(4'), 1.30m(4.265'), 1.524m(5), 1.60m(5.25') 3.Special sizes available at request 4.Packing:In waterproof paper, PVC bag, wooden case.Custom packing available at request.

Woven type	Mesh size	Wire diameter	Opening size
Plain dutch	7X40mesh	0.90X0.71mm	347μm
	7X44mesh	0.71X0.63mm	319μm
	8X45mesh	0.80X0.60mm	310μm
	8X85mesh	0.45X0.315mm	275μm
	8.5X60mesh	0.63X0.45mm	296μm
	10X76mesh	0.50X0.355mm	248μm
	10X90mesh	0.45X0.28mm	275μm
	12X64mesh	0.56X0.40mm	210μm
	12X86mesh	0.45X0.315mm	211μm
	12.5X76mesh	0.45X0.355mm	192μm
	14X76mesh	0.45X0.355mm	173μm
	14X100mesh	0.40X0.28mm	182μm
	14X110mesh	0.355X0.25mm	177μm
	16X100mesh	0.40X0.28mm	160μm
	16X120mesh	0.28X0.224mm	145μm
	17X120mesh	0.355X0.224mm	155μm
	20X110mesh	0.355X0.25mm	126μm
	20X140mesh	0.315X0.20mm	133μm
	20X170 mesh	0.25X0.16mm	130μm
	22X120 mesh	0.315X0.224mm	115μm
	24X110mesh	0.355X0.25mm	97μm
	25X140 mesh	0.28X0.20mm	100μm
	28X150mesh	0.28X0.18mm	92μm
	30X140 mesh	0.315X0.20mm	77μm
	30X150mesh	0.25X0.18mm	82μm
	35X170mesh	0.224X0.16mm	69μm
	35X190mesh	0.224X0.14mm	74μm
	40X200mesh	0.18X0.135mm	63μm
	45X250mesh	0.16X0.11mm	56μm
	50X250mesh	0.14X0.112mm	53μm
	50X270mesh	0.14X0.10mm	50μm
	50X300mesh	0.16X0.09mm	55μm
	60X270mesh	0.14X0.10mm	39μm
	60X300mesh	0.14X0.09mm	41μm
	60X500mesh	0.14X0.055mm	51μm
	65X390mesh	0.125X0.071mm	42μm
	65X750mesh	0.10X0.036mm	36μm
	70X340mesh	0.125X0.08mm	35μm
	70X350mesh	0.12X0.08mm	35μm
	70X390mesh	0.112X0.071mm
	70X400mesh	0.12X0.07mm
	70X930mesh	0.10X0.03mm	30μm
	77X560mesh	0.14X0.05mm	38μm
	80X350mesh	0.10X0.086mm
	80X400mesh	0.10X0.07mm	40μm
	80X430mesh	0.125X0.063mm	32μm
	80X600mesh	0.10X0.07mm	40μm
	80X700mesh	0.125X0.04mm	40μm
	100X600mesh	0.10X0.045mm
	100X800mesh	0.10X0.035mm
	100X1200mesh	0.063X0.023mm	23μm
Twill dutch wire mesh	20X150mesh	0.45X0.355mm	101μm
	20X200mesh	0.355X0.28mm	118μm
	20X270mesh	0.25X0.20mm	119μm
	24X300mesh	0.28X0.18mm	110μm
	30X270mesh	0.28X0.20mm	77μm
	30X340mesh	0.28X0.16mm	89μm
	40X430mesh	0.18X0.125mm	63μm
	40X540mesh	0.18X0.10mm	70μm
	50X500mesh	0.14X0.11mm	47μm
	50X600mesh	0.125X0.09mm	51μm
	65X600mesh	0.14X0.09mm	36μm
	70X600mesh	0.14X0.09mm	31μm
	78X680mesh	0.112X0.08mm	29μm
	78X760mesh	0.112X0.071mm
	80X680mesh	0.112X0.08mm	28μm
	90X760mesh	0.10X0.071mm	24μm
	90X850mesh	0.10X0.063mm	26μm
	100X760mesh	0.10X0.071mm	20μm
	100X850mesh	0.10X0.063mm	22μm
	130X1100 mesh	0.071X0.05mm	17μm
	130X1200mesh	0.071X0.045mm	18μm
	130X1500mesh	0.063X0.036mm	21μm
	150X1400mesh	0.063X0.04mm	15μm
	160X1500mesh	0.063X0.036mm
	165X1400mesh	0.063X0.04mm
	165X1500mesh	0.063X0.036mm	14μm
	174X1400mesh	0.063X0.04mm	11μm
	174X1700mesh	0.063X0.032mm	13μm
	203X1500 mesh	0.056X0.036mm	9μm
	203X1600mesh	0.05X0.032mm	10μm
	216X1800mesh	0.045X0.03mm
	250X1600 mesh	0.05X0.032mm
	250X1900mesh	0.04X0.028mm	8μm
	285X2100mesh	0.05X0.032mm
	300X2100mesh	0.036X0.025mm	6μm
	317X2100mesh	0.036X0.025mm	5μm
	325X2300mesh	0.036X0.024mm	4μm
	363X2300mesh	0.032X0.022mm
	400X2700mesh	0.028X0.02mm
	500X3500mesh	0.025X0.015mm	3μm
